Name: Factory Direct 200W Binocular Camera Module with Palm Vein Recognition USB Dynamic Infrared Global SDK Reset Feature
Brand: Shenzhen Tendcent Technology Co., Ltd.
SKU: TMS-P
Availability: InStock

Home Products Binocular Palm Vein Camera Module

Factory Direct 200W Binocular Camera Module with Palm Vein Recognition USB Dynamic Infrared Global SDK Reset Feature

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Tendcent
Model Number:	TMS-P

Contact Now

Detailed Product Description

Operation System:	Windows, Android, Linux, Wince, Mac Os	Special Features:	RESET, People Counting, Other
Customized Support:	Online Technical Support, Software Reengineering, OEM, ODM, Customized Logo, Online Technical Support	Display Type:	Other
Software:	Open SDK, Smart App	Packaging:	Box
Storage:	Memory Card	Power Source Type:	USB Powered
Type:	Binocular Wide Dynamic Camera,Palm Print And Vein Recognition Module	User Capacity:	50000
Product Name:	Palm Vein

Specification

Features
Support multiple encodings
Support UVC (driver-free protocol)
Support multiple operating systems
Adaptive digital noise reduction
Support maximum resolution of 1920x1080
Camera Module Key Parameters
Sensor	1/2.9-Inch CMOS Sensor
Resolution	1920 H x 1080 V
Pixel Size	2.8*2.8 µm
Dynamic Range	NC
Output Format	MGPEG,YUV2
FOV	DFOV:92°
Lens	FEL:3.2mm F/NO:2.4
Scanning Speed	0.1S
Focus Type	FF/ MF
Shutter Type	Electronic Rolling shutter
Output and Power Supply	High Speed UsB2.0
Interface	5 PIN 1.0 MM Socket
Controllable Parameters	Brightness, Contrast, Saturation, Hue, Sharpness, Gamma,White Balance, Backlight Contrast, Exposure
Supported system	Windows, Android, Linux, Mac OS
Cable Length	TBD
Minimum illumination	0.01Lux
Operating Voltage	USB DC +5V Supply
Operating Current	<200 mA
Operating Temperature	-20℃~60℃
Storage Temperature	-20℃~85℃

Product Description

Company Profile

FAQ

1. who are we?
We are based in Guangdong, China, start from 2012,sell to North America(20.00%),South America(20.00%),Eastern Europe(20.00%),Domestic Market(10.00%),Southeast Asia(5.00%),Oceania(5.00%),Mid East(5.00%),Western Europe(5.00%),Northern Europe(5.00%),Southern Europe(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Face recognition access control and attendance machine,Industrial computer,Face recognition alcohol detection machine,Palm vein recognition,Advertising display screen

4. why should you buy from us not from other suppliers?
null

5. what services can we provide?
Accepted Delivery Terms: null；
Accepted Payment Currency:null;
Accepted Payment Type: null;
Language Spoken:null
